All available sizes and tread patterns

E-3/L-3 S E-3/L-3 Z E-3/L-3 ZII E-3/L-3 ZIII E-3/L-3 XT3 E-4 E-4/L-4 L-4 XMH L-4 CM L-5 CM

Tyre Size: Ply Rating: Type
T.T.          T.L.		 Tread
Depth (mm):		 Section
Width (mm):		 Overall
Diameter (mm):		 Load Capacity
@ 50 km/h in Kg		 Load Capacity
@ 10 km/h in Kg

REGULAR BASE TYRE
12.00-24 16
20		 T.T.            ---
T.T.            ---		 61.0 343 mm. 1283 mm. 6.150
6.900		 ---
---
14.00-24 20
24		 T.T.           ---
T.T.           ---		 63.5 350 mm. 1359 mm. 8.500
9.500		 ---
---
16.00-25 24
28		 ---             T.L.
---             T.L.		 71.0 409 mm. 1488 mm. 10.600
11.500		 ---
---
18.00-25 24
28
32		 ---             T.L.
---             T.L.
---             T.L.		 78.5 493 mm. 1666 mm. 12.500
13.600
15.000		 ---
---
---
21.00-25 28 ---             T.L. 87.0 617 mm. 1796 mm. 16.500 ---
54/18-25 24
28		 ---             T.L.
---             T.L.		 63.5 432 mm. 1361 mm. 8.950
9.750		 ---
---

REGULAR BASE TYRE
17.5-25 16
20		 ---             T.L.
---             T.L.		 63.5 432 mm. 1361 mm. 7.300
8.250		 ---
---
20.5-25 16
20
24
28		 ---             T.L.
---             T.L.
---             T.L.
---             T.L.		 71.0 488 mm. 1494 mm. 8.250
9.500
10.300
11.500		 ---
---
---
---
23.5-25 16
20
24		 ---             T.L.
---             T.L.
---             T.L.		 78.5 564 mm. 1669 mm. 9.500
10.900
12.500		 ---
---
---
26.5-25 20
24
26
32		 ---             T.L.
---             T.L.
---             T.L.
---             T.L.		 87.0 698 mm. 1798 mm. 13.200
14.000
15.000
17.000		 ---
---
---
---
29.5-25 22
28		 ---             T.L.
---             T.L.		 101.5 770 mm. 1923 mm. 15.000
17.500		 ---
---
29.5-29 22
28
34		 ---             T.L.
---             T.L.
---             T.L.		 101.5 770 mm. 2052 mm. 16.000
19.000
21.200		 ---
---
---
33.25-29 24
30		 ---             T.L.
---             T.L.		 101.5 820 mm. 2088 mm. 19.500
23.000		 ---
---
37.25-35 36
42		 ---             T.L.
---             T.L.		 114.0 984 mm. 2418 mm. 30.750
33.500		 ---
---
37.5-39 36
42
44
52
58		 ---             T.L.
---             T.L.
---             T.L.
---             T.L.
---             T.L.		 114.0 993 mm. 2588 mm. 33.500
36.500
37.500
41.300
44.000		 ---
---
---
---
---

65 SERIES LOW PROFILE TYRE
35/65-33 24
30
32		 ---             T.L.
---             T.L.
---             T.L.		 101.5 853 mm. 2088 mm. 19.000
21.800
22.400		 ---
---
---
40/65-39 30
36		 ---             T.L.
---             T.L.		 114.0 1001 mm. 2423 mm. 27.250
30.750		 ---
---
45/65-45 38
46
52		 ---             T.L.
---             T.L.
---             T.L.		 118.0 1102 mm. 2723 mm. 38.750
43.750
47.300		 ---
---
---
