All available sizes and tread patterns

E-3/L-3 S E-3/L-3 Z E-3/L-3 ZII E-3/L-3 ZIII E-3/L-3 XT3 E-4 E-4/L-4 L-4 XMH L-4 CM L-5 CM

Tyre Size: Ply Rating: Type
T.T.          T.L.		 Tread
Depth (mm):		 Section
Width (mm):		 Overall
Diameter (mm):		 Load Capacity
@ 50 km/h in Kg		 Load Capacity
@ 10 km/h in Kg

WIDE BASE TYRE
23.5-25 16
20
24
28		 ---             T.L.
---             T.L.
---             T.L.
---             T.L.		 44.5 574 mm. 1613 mm. 9.500
10.900
12.500
13.600		 ---
---
---
---
26.5-25 20
24
28		 ---             T.L.
---             T.L.
---             T.L.		 54.0 635 mm. 1717 mm. 13.200
14.000
15.500		 ---
---
---
29.5-25 22
28		 ---             T.L.
---             T.L.		 57.0 780 mm. 1920 mm. 15.000
17.500		 ---
---
33.25-29 28 ---             T.L. 57.0 830 mm. 2096 mm. 21.200 ---
37.25-35 36
42		 ---             T.L.
---             T.L.		 70.0 998 mm. 2416 mm. 30.750
33.500		 ---
---
37.5-39 36
42		 ---             T.L.
---             T.L.		 70.0 1016 mm. 2586 mm. 33.500
37.500		 ---
---

65 SERIES LOW PROFILE TYRE
35/65-33 24
30
32		 ---             T.L.
---             T.L.
---             T.L.		 57.0 861 mm. 2088 mm. 19.000
21.800
22.400		 ---
---
---
40/65-39 30
36		 ---             T.L.
---             T.L.		 70.0 1011 mm. 2421 mm. 27.250
30.750		 ---
---
105/45-41 52 ---             T.L. 70.0 1062 mm. 2588 mm. 47.850 ---
